A/XMK Plus Cable - 240mm² to 1000mm²

Description

The A/XMK Plus is a single core aluminium cable with a Halogen free polyolefin, UV resistant Outer Sheath. The cable is manufactured for the construction industry in Finland. The outer sheath is self-extinguishing and halogen-free. Suitable for fixed installation indoors and outdoors.

Key Features

•
  Voltage Rating 600/1000 Volts
•
  Minimum Bending Radius 12 x Overall Diameter
•
  Temperature Limits Temperature Range: -40°C to +90°C
  Maximum Short Circuit Temperature: +250°C

Construction

• Conductor: AXMK: Class 2 round stranded and compact aluminium
  XMK: Class 2 round stranded and compact copper
• Insulation: Cross Linked polyethylene (XLPE)
• Outer Sheath: Halogen Free Polyolefin (PO)
• Sheath Colour: Black

Standards

• IEC 60502-1
• HD 603 S1
• BS EN/IEC 60332-1 (Cat B)
• IEC 60228
