LifY Single Core Cable-0.5mm² to 70mm²

Description

LiFY is a class 6 copper single core cable. It is a highly flexible power and control wiring cable most often in switch cabinets and measuring equipment found in laboratories and on portable testing equipment. It is similar to Tri rated cable though being more flexible does reduce its overall operating temperate range slightly. It is available in a range of 15 different colour sheaths.

Key Features

•
  Voltage Rating 0.5mm2 - 1mm²: 300/500V
  1.5mm² and above: 450/750V
•
  Minimum Bending Radius 8 x Overall Diameter
•
  Flame Retardancy BS EN/IEC 60332-1-2
•
  Temperature Limits Temperature Range: -15°C to +80°C

Construction

• Conductor: Flexible Copper Conductor
• Sheath: Polyvinyl Chloride (PVC)
• Sheath Colour: Various

Standards

• DIN VDE 0250
• BS EN/IEC 60332-1-2
• BS EN 50525-1
