Armoured AS/NZS 5000.1 XLPE PVC 1kV Cable-16mm² to 240mm²

Description

AS/NZS 5000.1 XLPE/SWA/PVC + Earth armoured cable is used for fixed wiring power distribution in applications that need mechanical protection, such as in industrial plants, residential and commercial buildings, and underground installations. It is suitable for use in mains, sub-mains, and sub-circuit power distribution networks within buildings and industrial plants and is widely used to power heavy machinery, large motors, and equipment in factories and processing plants.

It is heavily used in renewable sector systems like solar farms for connecting photovoltaic arrays. Due to being armoured with a PVC outer sheath, the cable is designed for direct burial or installation in underground ducts, providing protection against mechanical damage and environmental problems.

Key Features

•
  Voltage Rating 600/1000 Volts
•
  Minimum Bending Radius 10 x Overall Diameter
•
  Temperature Limits Maximum operating temperature: +90°C

Construction

• Conductor: Stranded copper conductor
• Insulation: Cross Linked polyethylene (XLPE)
• Bedding: Polyvinyl Chloride (PVC)
• Armour: Steel Wire Armour (SWA)
• Outer Sheath: Polyvinyl Chloride (PVC)
• Sheath Colour: Orange

Standards

• AS/NZS 1125
• AS/NZS 3008
• AS/NZS 5000.1

Core Colours
