Cleveland Cable is the UK’s leading supplier of fixed wiring cables for domestic and industrial projects where compliance with building and installation regulations is mandatory. Our extensive range of Low Voltage (LV) fixed wiring cables, all manufactured to British and IEC standards, ensures that you can find the perfect solution for your industrial and commercial applications.

624*B Surface Wiring, Twin & Earth – LSZH Sheathed Cable

This fixed installation cable is ideal for use:

  • Inside walls, on boards, or embedded in plaster
  • For domestic and industrial installations
  • In dry or damp environments
  • When clipped directly to surfaces, installed in trays, or run in free-air
  • Inside conduit or trunking where mechanical protection is required
  • Available in single, two or three core

Why Choose 624*B Cable?

  • Complies with BS 7211 and IEC standards
  • XLPE insulation for superior performance
  • Low Smoke Zero Halogen (LSZH) sheath for enhanced safety
  • Emits extremely low smoke and toxic gases in the event of a fire

624*B Twin & Earth Cables – Technical Specifications

Standards & Compliance

  • BS 7211
  • IEC 60754-1, IEC 60754-2
  • IEC 61034
  • BS EN/IEC 60332-1-2 – CPR Compliant
  • BASEC Approved

Construction

  • Conductor:
    • Up to 4mm² – Class 1 solid annealed compacted circular copper
    • Above 4mm² – Class 2 stranded plain annealed compacted circular copper
  • Insulation: Cross-Linked Polyethylene (XLPE)
  • Sheath: Low Smoke Zero Halogen (LSZH)
  • Sheath Colour: White

Characteristics

  • Voltage Rating: 300/500V
  • Operating Temperature Range: -25°C to +90°C
  • Minimum Bending Radius: As per the manufacturer’s datasheet
  • Installation Temperature Range: 0°C to +40°C

Core Identification (Colour Code)

  • 1 Core: Brown or Blue
  • 2 Core: Brown, Blue
  • 3 Core: Brown, Black, Grey

For any technical requirements, please get in touch with our Technical Sales Team.

Our cables undergo rigorous BSI Kitemark testing in our own UKAS-accredited ISO17025 laboratory. This ensures that they meet and exceed the stringent requirements of British and European standards, giving you peace of mind about their quality and compliance. For more information, contact the Cleveland Cable Sales Team.

6181B Surface Wiring Cable

  • Conductor: 1mm2 & 2.5mm -Solid conductor | Above 2.5mm2 - plain annealed stranded circular copper conductor single core
  • Insulation: Cross Linked polyethylene (XLPE)
  • Sheath: Low Smoke Zero Halogen (LSZH)
  • Sheath Colour: Grey or White

E618* Cables to Construction Compliance in Ireland

  • BS7211
  • IEC 60754-1, IEC 60754-2
  • IEC 61034
  • BS EN/IEC 60332-1-2 – CPR Compliant

Construction

  • Core: Class 2 Copper Conductor
  • Insulation: Cross-Linked Polyethylene (XLPE)
  • Sheath: LSZH (Low Smoke Zero Halogen)
  • Sheath Colour: Grey

Available in a range of single core, two, three & four core

Why Choose Cleveland Cable?

  • UK’s largest stockist of fixed wiring cables
  • High-quality, BASEC approved and European Standard-certified products
  • Competitive prices with fast UK & International delivery
  • Expert support for your cable requirements
  • In-house BSI testing lab for strict quality control

Order BS 6242B/BS7211 LSZH Fixed Wiring Cables Online

Cleveland Cable specialises in sourcing manufacturer-specific cables and developing custom cable solutions for fire-resistant and standard PVC installations. All of our cables are tested for compliance in our BSI-accredited lab.

Browse our range online or contact Cleveland Cable today for expert advice and bulk pricing
