Cleveland Cable is the UK’s largest supplier of PVC fixed wiring cables for domestic and industrial projects where compliance with building and installation regulations is mandatory. Our extensive range of PVC cables can be used for fixed installations, in trunking or conduit and can possibly be surface mounted. All manufactured to British and IEC standards, ensures that you can find the perfect solution for your industrial and commercial applications.
6491X Cable (H07V-R) BS EN 50525-2-3 – PVC Sheathed Cable
Applications:
- Inside walls, on boards, or embedded in plaster
- For domestic and industrial installations
- May be surface mounted
- When clipped directly to surfaces, installed in trays, or run in free air
- Inside conduit or trunking where mechanical protection is required
- Available in single only
Why Choose 6491X Cable?
- Flame Retardant
- PVC sheath for enhanced protection
- Compliant to British, Irish and European standards
Technical Specifications
Standards & Compliance
- BS EN 50525-2-3
- Flame propagation to BS EN 60332-2-1:2004+A1:2015
- BS EN/IEC 60332-1-2 – CPR Compliant
Construction
- Conductor: Stranded Annealed Copper Conductor (Class 2)
- Sheath: Polyvinyl Chloride (PVC)
- Sheath Colour: Various
Characteristics
- Voltage Rating: 450/750 Volts
- Operating Temperature Range: -25°C to +90°C
- Minimum Bending Radius: As per manufacturer’s datasheet
- Installation Temperature Range: 0°C to +40°C
6181Y Surface Wiring Cable
Applications:
- Fixed installations
- Domestic use
- Light industrial use
Technical Specification
Standards & Compliance
- BS6004
- Flame propagation to BS EN 50265 (IEC 60332)
- Flame propagation according to IEC/EN 60332-1-2
Construction
- Conductor: 1mm² & 2.5mm² – Solid; above 2.5mm² – Stranded Copper
- Insulation: Polyvinyl Chloride (PVC)
- Sheath: Polyvinyl Chloride (PVC)
- Sheath Colour: Grey or White
Twin & Earth Cable (624-Y)
Applications:
- Domestic wiring
- Fixed installation in dry or damp conditions
- Clipped direct to the surface
- On cable trays or in free air (with mechanical protection)
- In conduit or trunking
Technical Specification
Standards & Compliance
- BS6004
- Flame propagation: BS EN 50265, BS EN 50363-3
- BASEC approved (up to 35mm)
Construction
- Conductor: Up to 2.5mm² – Solid; from 4mm² – Stranded Copper
- Insulation: Polyvinyl Chloride (PVC)
- Sheath: Polyvinyl Chloride (PVC)
- Sheath Colour: Grey
For any technical requirements, please get in touch with our Technical Sales Team.
Our cables undergo rigorous BSI Kitemark testing in our own UKAS-accredited ISO17025 laboratory. This ensures that they meet and exceed the stringent requirements of British and European standards, giving you peace of mind about their quality and compliance. For more information, contact the Cleveland Cable Sales Team.
Why Choose Cleveland Cable?
- UK’s largest stockist of fixed wiring cables
- High-quality, BASEC approved and European Standard-certified products
- Competitive prices with fast UK & International delivery
- Expert support for your cable requirements
- In-house BSI testing lab for strict quality control
Order Twin & Earth Cable (624-Y) / 6491X(H07V-R) / 6181Y PVC Fixed Wiring Cables Online
Cleveland Cable specialises in sourcing manufacturer-specific cables and developing custom cable solutions for standard PVC installations. All of our cables are tested for compliance in our BSI-accredited lab.
Browse our range online or contact Cleveland Cable today for expert advice and bulk pricing
