High-Performance Marine and Offshore Cables for Demanding Environments
Cleveland Cable Company stocks a comprehensive range of marine and offshore cables for shipboard wiring, offshore platforms, and other marine installations supporting oil drilling, production, and power distribution. Our applications include power, control, signal, instrumentation, and communication systems.
Wide Range of Marine & Offshore Cable for Various Installations
- 657* TQ Cable 1.5mm² to 630mm² - EPR - LSZH Unbraided
- 658* TQ Cable 1.5mm² to 300mm² - Braided
- IEC60092-353 (XI & XAI) Shipboard Cable 1.5mm² to 25mm²
- UKOOA Marine & Offshore Cable 0.75 mm² to 1.5mm²
- NEK606 RFOU Power & Instrumentation Cable 0.75mm² to 240mm²
- NEK606 BFOU Power & Instrumentation Cable 0.75 mm² to 240mm²
Durable and Versatile Cables for Marine and Offshore Installations
Our marine and offshore cables are engineered and over-engineered to withstand the harshest conditions, including mud, oil, grease, and mechanical and thermal stress. Their robust construction ensures long-term reliability in corrosive environments, ensuring the performance of electrical and electronic systems on ships and offshore structures.
Manufactured to British and International Standards, Including:
- BS6883 – Fixed wiring in ships and offshore units
- BS7655 – Insulation and sheathing for marine use
- BS7917 – Fire-resistant cables for shipboard use
- iEC 60092 – 353(XI & XAI)
- NEK606
Additional Compliance With:
- IEC 60331, DNV (Det Norske Veritas), Lloyd’s Register of Shipping
Marine Cable Specifications
657*TQ Marine Cable – BS6883
Unarmoured power, control, and lighting cable in fixed installations across all ship areas, including open decks (where no mechanical damage risk exists).
- Conductor: Class 2 & Class 5 Tinned copper (1.5mm² to 630mm²)
- Insulation: EPR
- Sheath: LSZH – Black (multi-core), Black & Green-Yellow (single core)
- Voltage: 600/1000V
- Temp Range: -40°C to +90°C
- Standards: BS6883, IEC60332-1, IEC60332-3-22, IEC60754-1/2, IEC61034-1/2
658*TQ Armoured Marine Cable – BS6883
Armoured cable for fixed offshore installations, decks, rigs, and platforms.
- Conductor: Class & Class 5 Tinned copper (1.5mm² to 300mm²)
- Insulation: EPR
- Bedding & Sheath: LSZH
- Armouring: Galvanised steel wire braid
- Temp Range: -40°C to +90°C
- Standards: BS6883, IEC60332-1, IEC60332-3-22, IEC60754-1/2, IEC61034-1/2
- 6591TQ single core with phosphor bronze braid armour
IEC60092-353 (XI & XAI) Shipboard Cable
Unarmoured cable for fixed installation in marine electromechanical/electronic systems. Flame-retardant and halogen-free for fire safety.
- Conductor: Flexible tinned/stranded copper (1.5mm² to 25mm²)
- Insulation: XLPE
- Armour: Plain or tinned copper wire braid or GSW8
- Sheath: Halogen-free compound – Black
- Voltage: 600/1000V
- Temp Range: -40°C to +90°C
- Standards: IEC60092-353, IEC60228 Class 2, IEC60754-1/2, IEC60332-1/3-22 Cat.A, IEC61034-1/2
Screened Marine & Offshore Cable
Designed for emergency systems, gas detection, alarms, and control rooms.
- Conductor: Tinned copper (0.75mm² to 2.5mm²)
- Insulation: EPR GP4
- Screen: Aluminium-backed polyester with tinned copper drain wire
- Sheath: LSZH SW4 – Grey, Blue, Black
- Voltage: 150/250V
- Temp Range: -40°C to +90°C
- Variants: Fire-resistant, individually/collectively screened
- Standards: BS7917, BS6883, IEC standards listed above
NEK606 RFOU Power Cable
Halogen-free, mud-resistant cable for marine installations in muddy, wet, dry, or oily environments.
- Conductor: Copper 1.5mm² to 300mm² | (Available in Pairs/Triples)
- Insulation: EPR
- Armour: Tinned copper braid
- Sheath: Mud-resistant – Black
- Voltage: 600/1000V (Power)
- Temp Range: -40°C to +90°C
- Standards: NEK606, IEC60228 Class 2, IEC60332-3/A, IEC61034-1/2
RFOU Instrumentation Cable
- Conductor: Copper 0.75mm² - 2.5mm²
- Insulation: EPR
- Armour: Tinned Copper braid
- Sheath: Mud-resistant - black
- Voltage: 150 - 250V
- Temp Range: -40°C to +90°C
- Standards: NEK606, IEC60228 Class 2, IEC60332-3/A, IEC61034-1/2
NEK606 BFOU Power Cable
A fire-resistant version of RFOU cable for critical systems.
- Conductor: Copper (1.5mm² to 300mm²)
Available in Pairs/Triples - Sheath: Mud-resistant – Black, Blue, Grey
- Voltage: Same as RFOU
- Standards: Same as RFOU
BFOU Instrumentation Cable
- Conductor: Copper 0.75mm² - 2.5mm²
- Insulation: EPR
- Armour: Tinned Copper braid
- Sheath: Mud resistant - black
- Voltage: 150 - 250V
- Temp Range: -40°C to +90°C
- Standards: NEK606, IEC60228 Class 2, IEC60332-3/A, IEC61034-1/2
Why Choose Cleveland Cable?
As a BASEC-accredited distributor, we stock marine cables engineered for extreme temperatures, humidity, saltwater, oil, and mud exposure.
- UK’s largest stockist of marine and offshore cables
- Products certified to UK and European Standards
- Competitive pricing with fast UK and international delivery
- Expert support from cable specialists
- In-house BSI testing lab for quality assurance
Order Marine and Offshore Cables Online or Contact Us
Are you looking for high-performance marine and offshore cables?
Browse our range online or contact Cleveland Cable for bulk pricing and expert advice today
