Buy Solar Energy Cable | Cleveland Cable - UK's Largest Stockist
High-Quality Solar Cables for Renewable Energy Systems
Cleveland Cable is the UK's largest supplier of photovoltaic (PV) solar cables designed for connecting solar panel arrays to power supplies in domestic and industrial renewable energy systems. Manufactured to BS EN 50618 under the harmonised standard H1Z2Z2-K, and are T.U.V approved. These cables ensure efficiency and durability. Our solar cables are suitable for fixed installations in both indoor and outdoor environments, including conduits and open systems. Their robust sheathing makes them ideal for direct burial applications, with water resistance options of AD7 or AD8.
Wide Range of Solar Energy Cables
- Solar Energy Cable to BS EN 50618 (H1Z2Z2-K) – AD8, 1.5mm² to 240mm² - Red & Black
- Solar Energy Cable to BS EN 50618 (H1Z2Z2-K) – AD7, 1.5mm² to 240mm² - Red & Black
- Doncaster Cables PV Ultra Solar Cable with Black Tuff outer sheath
Browse our full range online or speak to our team for expert advice.
Durable & Versatile Solar Cables
These LSZH (Low Smoke Zero Halogen) sheathed cables reduce smoke and gas emissions, making them safer for installation in residential, commercial, and industrial solar systems.
Key Features & Benefits:
- Suitable for roof mounting, direct burial, and conduit installations
- High flame resistance for added safety
- UV, ozone, and weather-resistant for long-term durability
- AD7 & AD8 versions available from stock
For more complex setups, solar energy cables may need to be combined with medium voltage cables.
Solar Energy Cable Construction & Specifications
This Class 5 flexible standard solar energy cable is manufactured to BS EN 50618 and complies with the H1Z2Z2-K standard.
- Conductor: Electrolytic annealed flexible tinned copper
- Insulation & Sheath: Cross-linked halogen-free compound
- Sheath Colours: Black or Red
- Voltage Rating: 600V–1000V AC, 1800V DC
- Test Voltage: 6.5kV AC
- Operating Temperature: -40°C to 90°C
- Short Circuit Temperature: 250°C (max 5s)
Complies with BS EN 50618, IEC 60332-1-2, IEC 60754, T.U.V, IEC 61034, EN 50395, and UV resistance standards.
Doncaster Cables PV Ultra Solar Cable – Black Tuff Sheath
Designed for DC interconnections in solar power systems, this cable provides excellent mechanical strength and long-term durability of up to 25 years.
- Conductor: Tinned annealed copper (Class 5 Flexible)
- Insulation: Double insulated, cross-linked to BS EN 50618 Annex B
- Bedding: CarbonTek®
- Armour (where applicable): Galvanised steel wire
- Sheathing: SolarTek®
Benefits of PV Ultra Solar Cable:
- Easier installation & handling
- Saves time and costs
- Enhanced durability & mechanical strength
- Reduces accidental damage risk
- Clearly marked “LIVE DC” warning for safety
For more details, contact our Cleveland Cable Sales Team.
Why Choose Cleveland Cable?
- UK’s Largest Stockist of Solar Cables
- Certified to British & European Standards
- Competitive Pricing & Bulk Discounts
- Fast UK & International Delivery
- BSI-Accredited In-House Testing for Quality Assurance
Order Solar Energy Cables Online or Contact Us
Find the right solar energy cable for your project.
Browse our range online or contact our team for expert guidance and bulk order pricing
