Cleveland Cable is the UK’s largest supplier of 6kV to 36kV copper or aluminium conductors, steel wire armoured (SWA) or aluminium wire armoured (AWA), PVC sheathed or LSZH (Low Smoke Zero Halogen) sheathed medium voltage cable. Medium voltage cable is usually selected for use in power infrastructure applications, such as national grid connections, wind-farm installations, or generator and substation connections. Where applicable, our medium voltage cables are manufactured in accordance with British Standards BS6622, BS7870, or BS7835.

Wide Range of Medium Voltage Cable 6kV to 36kV for Various Installations

• BS 6622 Single Core Mains Power Cable 11kV - Copper, XLPE, CTS, PVC, AWA, PVC (50mm to 630mm²)
• BS 6622 3 Core Mains Power Cable 11kV - Copper, XLPE, CTS, PVC, SWA, PVC (35mm to 400mm²)
• BS 6622 3 Core Mains Power Cable 11kV - Aluminium, XLPE, SWA, PVC (95mm to 300mm²)
• BS7870 Triplex Cable 11KV and 22KV - Aluminium, XLPE, Copper Screen, MDPE (70mm to 300mm²)
• BS 7835 3 Core Armoured Mains Cable 22KV - Aluminium/Copper, XLPE, CTS, LSZH, SWA, LSZH (35mm to 400mm²)
• BS 7835 Single Core Armoured Power Cable 22KV - Copper, XLPE, CTS, SWA, PVC (50mm to 630mm²)

Durable & Medium Voltage Cable 6kV to 36kV for Any Installation

Medium Voltage cables cover a huge number of variations in construction, standards, and materials. Choosing the correct MV cable involves balancing performance requirements, installation demands, and environmental factors while ensuring compliance with regulations and standards.

BS 6622 Mains Power Cable

• Conductor: Stranded Plain Annealed Circular Compacted Copper or aluminium Conductors
• Insulation: Cross Link Polyethylene (XLPE)
• Metallic Screen: Individual or overlapped copper tape screen
• Bedding: Polyvinyl Chloride (PVC)
• Separator: Copper Tape with 10% overlap
• Armouring: Galvanised Steel Wire Armour
• Sheath: PVC outer sheath
• Voltage Rating: 6350/11000 Volts (12KV)
• Temperature Rating: -15°C to +90°C

BS7870 Copper and Aluminium 11kV Power Cable

• Conductor: Stranded Aluminium or Aluminium Conductors
• Insulation: Triple layer, Cross Link Polyethylene (XLPE)
• Metallic Screen: Copper Wire Screen
• Sheath: Medium Density Polyethylene (MDPE-UV stabilized)
• Maximum Operating Temperature: 130°C
• Short Circuit Temperature: 250°C

Medium Voltage Cable BS7835 11kV & 22kV Construction & Specifications

• Conductor: Stranded Plain Annealed Circular Compacted Copper Conductors/Aluminium
• Insulation: Cross-Linked Polyethylene (XLPE)
• Metallic Screen: Overall copper tape screen
• Armour: Steel Wire Armoured (SWA)
• Sheath: Low Smoke Zero Halogen (LSZH)
• Voltage Rating: 22000 Volts
• Temperature Limits: -15°C to +90°C

Why Choose Cleveland Cable?

• UK’s largest stockist of MV/HV Cable 6kV to 36kV
• High-quality, British and European Standard certified products
• Competitive prices with fast UK & International delivery
• Expert support for your cable requirements
• In-House BSI testing lab to ensure the highest quality maintained in the supply chain
