2192Y H03VVH2-F EN 50525-2-11 PVC Insulated Flexible Cord 0.5mm² to 0.75mm²

Description

2192Y is a two core, flexible PVC insulated & sheathed light duty cord.  For use in domestic properties,  kitchens, bathrooms and offices for pendant light drops and light supply leads where only two cores are used. 2192Y cable is manufactured to  BS 6500 and EN 50525-2-11 and meets harmonised code H03VVH2-PVC. Available in 100M reels

Key Features

•
  Voltage Rating 300/300 Volts
•
  Minimum Bending Radius 8 x Overall Diameter
•
  Flame Retardancy BS EN/IEC 60332-1-2
•
  Temperature Limits Temperature Range: -5°C to +70°C

Construction

• Conductor: Class 5 Flexible stranded copper
• Insulation: Polyvinyl Chloride (PVC)
• Outer Sheath: Polyvinyl Chloride (PVC)
• Sheath Colour: White

Standards

• BS EN 50525-2-11
• BS EN/IEC 60228
• IEC/EN 60332-1-2
• Conforms to H03VVH2-F

Core Colours
