H07RN-F Cable

H07RN-F Cable

Product Overview

Flexible EPR cable with high resistance to mechanical stress. Able to withstand water and weather, it is suitable for fixed and temporary installation works on work sites, mobile power supplies, ports and harbours, water treatment plants, sewage and drains, hot and cold areas, and harsh industrial environments.

Featuring a UV-resistant sheath, this cable is ideal for portable power supplies, site equipment, industrial machinery, and audio visual equipment. It can also be cut to size for patch leads, with a choice of fittings available.

Key Features

  • Voltage Rating: Fixed: 0.6kV - 1kV, Flexing: 450/750 Volts
  • Minimum Bending Radius: Fixed: 4x overall diameter, Flexing: 6x overall diameter
  • Flame Retardancy: IEC/EN 60332-1-2
  • Temperature Limits: Fixed: -30°C to +90°C, Flexing: -15°C to +90°C

Construction

  • Conductor: Class 5 flexible stranded copper conductor
  • Insulation: Ethylene Propylene Rubber (EPR)
  • Outer Sheath: Polychloroprene Rubber (CR)
  • Sheath Colour: Black

Standards

  • BS EN 50525-2-21
  • BS EN/IEC 60332-1-2
  • BS EN/IEC 60228
  • Conforms to H07RN-F

Core Colours

  • 2 core: Blue, Brown
  • 3 core: Brown, Blue, Green / Yellow
  • 4 core: Brown, Blue, Grey, Green/Yellow
  • 5 core: Brown, Black, Grey, Blue, Green/Yellow
  • 6 core: and above: Black with White numbers plus Green/Yellow
