Extremeflex90
Product Overview
Flexible 90°C EPR cable with high resistance to mechanical stress. Able to withstand water and weather. For use in fixed and temporary installation works on Work sites, mobile power supplies, ports and harbours, water treatment plants, sewage and drains, hot and cold areas and harsh industrial environments. UV Resistant Sheath. Extremeflex90 is suitable for burial in ducts.
For use in portable power supplies, site equipment, industrial machinery, and audio visual equipment. Can be cut to size for temporary power leads with a wide choice of terminals and connections.
Available sizes: From 1mm² to 630mm², in various core configurations and lengths.
It can be cut to standard 5m, 10m, 15m, 25m patch leads or any bespoke length fitted with a wide range of terminals.
Key Features
- Voltage Rating: Fixed: 0.6kV - 1kV, Flexing: 450/750 Volts
- Minimum Bending Radius: (Less than 12mm²): 3 X Overall Diameter, (More than 12mm²): 4 X Overall Diameter
- Flame Retardancy: IEC/EN 60332-1-2
- Temperature Limits: -40°C to +90°C,
Construction
- Conductor: Class 5 flexible stranded copper conductor
- Insulation: Ethylene Propylene Rubber (EPR)
- Outer Sheath: Polychloroprene Rubber (CR)
- Sheath Colour: Black
Standards
- BS EN 60811-2-1
- BS EN 60228
- BS EN/IEC 60332-1-2
- UV Resistant Sheath
- BBS EN 50363
- AD8 water resistance
- Conforms to H07RN-F
Core Colours
- 2 core: Blue, Brown
- 3 core: Brown, Black, Blue, Green / Yellow
- 4 core: Brown, Black, Blue, Grey or Brown, Black, Green/Yellow, Grey
- 5 core: Brown, Black, Grey, Blue, Green/Yellow
- 7 core: and above: Black with White numbers plus Green/Yellow
