Cleveland Cable is the UK’s largest supplier & stockist of steel wire armoured (SWA) cables, offering an extensive range of low voltage (LV) armoured cables. Our high-quality cables are manufactured to British and IEC Standards and ideal for a wide variety of industrial, commercial, and underground applications.
Wide Range of SWA Armoured Cables for Various Installations
- Sizes from 1.5 mm² up to 400mm²
- Available up to 48 core x 2.5 mm²
- 2, 3, 4 or 5 core 1.5mm² & 2.5mm² are black with white numbered cores to ESI 09-6
- 2, 3, 4 or 5 core - colour coded
- 5 core and above up to 6mm² are black with white numbered cores
- 25mm² to 400mm² available up to five cores
- 3 core cable available with Brown / Black / Grey, or Brown / Blue / Green - Yellow cores
- European equivalent to UK 600/1000V BS5467 and BS6724 cables
Durable & Versatile Armoured Cables for Any Installation
Our armoured power and control cables are perfect for domestic and commercial power applications. Suitable for direct burial, outdoor, and underground installations, offering superior protection against mechanical stress. These cables suit various industrial, commercial, and telecommunications applications.
N2XRY Cable Construction & Specifications
- Conductor: Class 2 stranded copper
- Insulation: Cross-Linked Polyethylene (XLPE)
- Bedding: PVC (Polyvinyl Chloride)
- Armour: SWA (Steel Wire Armour)
- Sheath: PVC (Polyvinyl Chloride)
- Voltage Ratings: 600/1000V
Complies with British, IEC, and international standards, including: N2XRY, BS5467, IEC 60502-1, IEC 60228. Flame retardant to IEC 60332-1-2. These cables are BASEC approved.
N2XRH Cable Construction & Specifications
- Conductor: Class 2 stranded copper
- Insulation: Cross-Linked Polyethylene (XLPE)
- Bedding: LSZH (Low Smoke Zero Halogen)
- Armour: SWA (Steel Wire Armour)
- Sheath: LSZH (Low Smoke Zero Halogen)
- Voltage Ratings: 600/1000V
Complies with British, IEC, and international standards, including: N2XRH, BS6724, BS EN 50265, BS EN 50266. Flame retardant to IEC 60332-1-2. Acid gas emission to IEC 60754-1, Smoke emission to IEC 61034. These cables are BASEC approved.
Why Choose Cleveland Cable?
- UK’s largest stockist of SWA cables
- High-quality, European Standard-certified products
- Competitive prices with fast UK & International delivery
- Expert support for your cable requirements
- In-House BSI testing lab to ensure the highest quality maintained in the supply chain
Order Armoured Cables Online or Contact Us
Looking for N2XRY or N2XRH multi-core armoured power & control cables?
Browse our range online or contact Cleveland Cable today for expert advice and bulk pricing
