Protected fixed wiring cable is an alternative cable which can be used in place of steel wire armoured cables or singles cables in conduit for fixed wiring installations. This BS8436 cable can be used for ring main power, lighting, air conditioning and heating systems. Due to being lighter and smaller than armoured cables, these cables can offer savings on installation time and costs. The cable is XLPE insulated and has a bonded aluminium tube armour with a white LSZH outer sheath.
Full Range of Protected Wiring Cable
- Class1 up to 4mm2 or 6mm2 + = Class 2
- Different sheath and core colours available on request
- 10mm² and 16mm² available on request
- Voltage rated 1.5mm² to 4mm²: 300/500V, 6mm² and above: 600/1000V
Durable & Versatile Cables for Any Installation
Intended for installation in air (which includes installation in trunking or other closed systems), and in thin partitions and building voids when connected to a suitably selected protective device.
When cables are to be installed in any other environment, reference should be made to the cable manufacturer.
Protected Wiring Cable - Construction & Specifications
- Conductor: Plain Annealed Solid & Stranded Copper
- Earth: Bare tinned annealed copper earth wire
- Insulation: Cross linked Polyethylene (XLPE)
- Armouring: Bonded Aluminium Tube
- Sheath: Low Smoke Zero Halogen (LSZH)
Complies with British and international standards: 1mm²– 4mm² & 10mm² to BS8436, 6mm² and above manufactured to IS273. BS EN 50267-1:1998. Acid gas emissions to BS EN 50267-2-1. Smoke emissions to BS EN 50268-2.
Why Choose Cleveland Cable?
- UK’s largest supplier of Protected Wiring Cable
- High-quality, BASEC and International Standard-certified products
- Competitive prices with fast UK & International delivery
- Expert support for your cable requirements
- In-House BSI testing lab to ensure the highest quality maintained in the supply chain
Order Protected Wiring Cable Online or Contact Us
As the UK’s largest supplier of cables and cable accessories, Cleveland Cable Company can supply a wide range of alternative cables which provide savings in installation time, weight and money.
Looking for Protected Wiring Cable?
Our expertise in Protected Wiring Cable lies in our ability to source alternative cables from a large range of manufacturers who design and manufacture specifically for us against a supplied specification. Our high-performance cable solutions are tested for quality and compliance in our BSI Accredited Lab.
Browse our range online or contact Cleveland Cable today for expert advice and bulk pricing
