Cleveland Cable Company holds the UK’s largest stock of 0.6/1kV LV Waveform cables, featuring 3 or 4-core solid segmented aluminium conductors. These DNO-approved cables come with XLPE insulation and a PVC or LSZH outer sheath for durability.
Waveform cables (also called Wavecon cables) are available for same-day global delivery and are approved for use in areas managed by UKPN, NIE, SSE, WPD, NPG, ENW, and SPEN.
Wide Range of Waveform Cables
- Solid Aluminium Conductors (95mm² – 300mm²)
- Outer sheath options in PVC or LSZH
- DNO-approved cables for UKPN, NIE, NIE, SSE, WPD, NPG, ENW, and SPEN
Versatile & Durable Cables for Power Distribution
Waveform cables are essential for power station distribution, panel boards, and street lighting. They feature 3 or 4 aluminium conductors in a sector shape, with a waveform-laid copper conductor for efficient power distribution.
Technical Specifications
PVC Low Voltage Aluminium Waveform Cable
- Conductor: Class 1 Solid Aluminium
- Insulation: Cross-Linked Polyethylene (XLPE)
- Separator: Binding Tape
- Bedding: Extruded Rubber Compound
- Waveform Conductor: Plain Copper Wire Screen
- Sheath: Poly Vinyl Chloride (PVC) with UV Additive
- Sheath Colour: Black
- Compliance: BS7870-3.40, BS7870-1, BS EN 60228
LSZH Low Voltage Aluminium Waveform Cable
- Conductor: Class 1 Solid Aluminium
- Insulation: Cross-Linked Polyethylene (XLPE)
- Separator: Binding Tape
- Bedding: Extruded Rubber Compound
- Waveform Conductor: Plain Copper Wire Screen
- Sheath: Low Smoke Zero Halogen (LSZH)
- Sheath Colour: Orange
- Compliance: BS7870-3.50, BS7870-1, IEC/EN 60228, IEC/EN 61034-1/2
All cables are manufactured to DNO specifications from G81-approved suppliers.
Why Choose Cleveland Cable?
- UK’s largest stockist of DNO LV Waveform Power Cables
- Certified to British & IEC standards for reliability
- Competitive pricing with fast UK & international delivery
- Expert technical support for all cable requirements
- BSI-accredited testing lab ensures strict quality control
Order Waveform Power Cables Online or Contact Us
Looking for DNO-approved LV Waveform Cables? Cleveland Cable offers high-performance solutions for modern and legacy installations.
Browse our range online or contact us today for expert advice & bulk pricing
