Marine & Offshore Cables

Cleveland Cable Company is the largest stockist of marine and offshore cables for shipboard wiring, offshore platforms, and other marine installations supporting oil drilling, production, and power distribution. Our applications include power, control, signal, instrumentation, and communication systems.

Wide Range of Marine & Offshore Cable for Various Installations

Durable and Versatile Cables for Marine and Offshore Installations

Our marine and offshore cables are engineered and over-engineered to withstand the harshest conditions, including mud, oil, grease, and mechanical and thermal stress. Their robust construction ensures long-term reliability in corrosive environments, ensuring the performance of electrical and electronic systems on ships and offshore structures.

Manufactured to British and International Standards, Including:

BS6883 – Fixed wiring in ships and offshore units
BS7655 – Insulation and sheathing for marine use
BS7917 – Fire-resistant cables for shipboard use
IEC 60092 – 353(XI & XAI)
NEK606

Additional Compliance With:

IEC 60331, DNV (Det Norske Veritas), Lloyd’s Register of Shipping

Marine Cable Specifications

657*TQ Marine Cable – BS6883

Unarmoured power, control, and lighting cable in fixed installations across all ship areas, including open decks (where no mechanical damage risk exists).

Conductor: Class 2 & Class 5 Tinned copper (1.5mm² to 630mm²)
Insulation: EPR
Sheath: LSZH – Black (multi-core), Black & Green-Yellow (single core)
Voltage: 600/1000V
Temp Range: -40°C to +90°C
Standards: BS6883, IEC60332-1, IEC60332-3-22, IEC60754-1/2, IEC61034-1/2

Range: We supply 657*TQ Marine Cable in a wide range of conductor sizes:

Single Core: 1.5mm² – 630mm²
2 core: 1.5mm² – 150mm²
3 core: 1.5mm² – 120mm²
4 core: 1.5mm² – 95mm²
5 core: 1.5mm² – 6mm²
6 & 7 core: 1.5mm² – 4mm²
8,10,12,19, 27,30 & 37 core: 1.5mm² – 2.5mm²

658*TQ Armoured Marine Cable – BS6883

Armoured cable for fixed offshore installations, decks, rigs, and platforms.

Conductor: Class & Class 5 Tinned copper (1.5mm² to 300mm²)
Insulation: EPR
Bedding & Sheath: LSZH
Armouring: Galvanised steel wire braid
Temp Range: -40°C to +90°C
Standards: BS6883, IEC60332-1, IEC60332-3-22, IEC60754-1/2, IEC61034-1/2

Range: We supply 658*TQ Marine Cable in a wide range of conductor sizes:

2 core: 1.5mm² – 150mm²
3 & 4 core: 1.5mm² – 300mm²
5 core: 1.5mm² – 4mm²
6 core: 1.5mm² – 2.5mm²
7 core: 1.5mm² – 4mm²
12,19, 27 & 37 core: 1.5mm² – 2.5mm²

6591TQ Marine Cable & Offshore Cable - BS6883

Marine and offshore armoured cable. Suitable for power, control and lighting for fixed installations in all areas in ships and offshore units including accommodation and open decked areas exposed to the elements.

Conductor: Class 2 stranded tinned copper
Insulation: Ethylene Propylene Rubber (EPR)
Inner Sheath: SW4 Low smoke zero Halogen (LSZH)
Armour: Tinned Phosphorous Bronze Wire Braid (TPBWB)
Outer Sheath: SW4 Low smoke zero Halogen (LSZH)
Temp Range: -40°C to +90°C
Standards: BS6883, IEC 61034-1, IEC/EN 60754-1/2, BS EN/IEC 60228, IEC 60331-21, BS EN/IEC 60332-2-22, BS EN/IEC 60332-2

Range: Single core in sizes 6mm² to 630mm²

IEC60092-353 (XI & XAI) Shipboard Cable

Unarmoured cable for fixed installation in marine electromechanical/electronic systems. Flame-retardant and halogen-free for fire safety.

Conductor: Flexible tinned/stranded copper (1.5mm² to 25mm²)
Insulation: XLPE
Armour: Plain or tinned copper wire braid or GSW8
Sheath: Halogen-free compound – Black
Voltage: 600/1000V
Temp Range: -40°C to +90°C
Standards: IEC60092-353, IEC60228 Class 2, IEC60754-1/2, IEC60332-1/3-22 Cat.A, IEC61034-1/2
