Mining Cables designed specifically to meet industry needs and standard BS6708, covering an extensive range of open-cast mining, underground mining and tunnelling equipment. The mining cables are specifically manufactured for connection of large machines in environments where cables are exposed to high mechanical stresses, abrasion or wear and tear in trailing cable applications. Our cables supply excavators, coal cutters, crushing machines and similar rock face equipment, roadways and lighting systems.

Wide Range of Mining, Drilling & Tunnelling Cable for Various Installations

We stock a comprehensive selection of 1100V and 3300V Mining, Drilling & Tunnelling Cable, including:

Durable & Versatile Mining, Drilling & Tunnelling Cable for Any Installation

Our range of mining cables cover moving plant and static equipment in 1100V and 3300V applications. Our cables guarantee the supply of power in the most challenging working environments. Cleveland Cable Company mining and tunnelling cables are supplying power to the world’s largest tunnelling projects. All cables meet IEC 60228 and BS6708.

BS6708 Type 20/21 Mining Cable Construction & Specifications

Conductor: Electrolytic, stranded, tinned copper wire IEC 60228 Class 5
Insulation: Ethylene propylene rubber (EPR)
Layup: Cores are laid up over a cradle without contacting each other
Bedding: Rubber based bedding compound
Armour: Galvanized steel pliable armour
Outer Sheath: Heavy duty chloroprene outer sheath
Voltage Ratings: 640/1100V
Temperature Limits: -20°C to +85°C

Why Choose Cleveland Cable?

UK’s largest stockist of Mining, Drilling & Tunnelling cables
High-quality, British and European Standard-certified products
Competitive prices with fast UK & International delivery
Expert support for your cable requirements
In-House BSI testing lab to ensure the highest quality maintained in the supply chain
