High-Quality Fire-Resistant Cables for Critical Safety Systems
Cleveland Cable is the UK’s largest supplier of British and European Standard fire-resistant cables for emergency lighting and fire detection systems. Our cables ensure power and signal integrity in emergency situations, making them essential for public buildings, commercial properties, and high-rise developments.
Wide Range of Fire-Resistant Cables
Standard Fire-Resistant Cables (30-Minute Fire Survival)
Designed for use in low-rise buildings up to 10 storeys, these cables meet BS EN 50200 (PH 30) standards and continue operating for a minimum of 30 minutes under fire conditions.
- BS5839/BS7629 Fire Alarm & Security Cable (1mm² – 4mm²)
- IEC 331, BS6387 & BS7629-1-2008 Compliant
- Low Smoke Zero Halogen (LSZH) Sheathing
- BS EN 50265 & IEC 60360134 Flame Propagation Compliance
Enhanced Fire-Resistant Cables (120-Minute Fire Survival)
Recommended for multi-phase evacuation systems, tower blocks, and critical infrastructure, these cables operate for up to 120 minutes in fire conditions.
- BS5839/BS7629 Enhanced Fire Alarm & Security Cable (1.5mm² – 4mm²)
- BS 8519:2020 Category 2 & BS 8434-2:2003 +A2:2009 Compliant
- Fire, Mechanical Shock & Water Resistance Tested (930°C)
- Verified In-House by BSI Testing Lab
Technical Specifications & Compliance
Standard Fire-Resistant Cable Construction
- Conductor: 1.5mm² - 2.5mm² (Class 1 solid), 4mm² (Class 2 stranded) per BS EN 60228
- Insulation: Fire-resistant MICA tape or silicone rubber
- Screen: AL/PET (Aluminium/Polyester Tape), Circuit Protective Tinned Copper
- Sheath: Low Smoke Zero Halogen (LSZH)
- Voltage Rating: 300/500V
- Temperature Limits: -40°C to +90°C
- Bending Radius: As per the manufacturer’s datasheet
Enhanced Fire-Resistant Cable Construction
- Similar to standard but with additional insulation layers for enhanced fire performance
- Fully compliant with BS 5839-1:2017, BS EN 50200:2015 PH30, PH60, PH120, and BS 6387:2013 CWZ
Why Choose Cleveland Cable?
- UK’s Largest Stockist of Emergency Lighting & Fire Detection Cables
- Certified British Standard (BS) & BASEC-Approved Products
- Competitive Prices with Fast UK & International Delivery
- Expert Advice & Technical Support for Contractors
Browse our full range online or contact Cleveland Cable today for expert advice and bulk pricing
Fire Alarm & Security
Standard Fire Alarm & Security Cable BS5839, BS7629 1mm - 4mm
Enhanced Fire Alarm & Security Cable BS5839, BS7629 - 1.5mm - 4mm
