Cleveland Cable Company holds the most extensive UK stock of NYY and N2XH cables, which are widely used in European power distribution for fixed installations. These cables, with a voltage rating of 600/1000V, are ideal for domestic, commercial, and public buildings, providing the necessary power supply for various applications.
N2XH cables feature a flame-retardant, low smoke zero halogen (LSZH) outer sheath. This unique feature makes them suitable for environments where smoke and corrosive gases could pose a risk to life and sensitive equipment in the event of a fire, ensuring safety and protection.
Versatile & Durable Unarmoured Power Cables
NYY and N2XH cables are unarmoured power and control cables designed for energy supply in fixed installations. They can be installed:
- Indoors, where the risk of mechanical damage is low
- Outdoors, in open air
- Underground, with appropriate external protection
- In dry and damp environments, under plaster, in walls, masonry, and concrete
Note: These cables must not be directly buried without external protection against mechanical stress or water.
Full Range of NYY & N2XH Cables
- Copper conductors: 1.5mm² to 400mm²
- IEC 60228 Class 1 (up to 6mm²) and Class 2 (10mm² and above)
- Class 5 conductors are available for additional flexibility
- Insulation and outer sheath options: PVC or LSZH
- N2XH KEMA-approved version available up to 500mm²
- Voltage rating: 600/1000V
NYY Cables – Construction & Specifications
- Conductor: Up to 6mm²: Class 1 solid copper
- Above 10mm²: Class 2 stranded copper
- Insulation: PVC (Polyvinyl Chloride)
- Filler: PVC (Polyvinyl Chloride)
- Sheath: PVC (Polyvinyl Chloride)
Standards & Compliance
- BS 6004, IEC 60502-1, EN 60228
- Flame retardant, according to IEC/EN 60332-3-24
N2XH Cables – Construction & Specifications
- Conductor: Up to 6mm²: Class 1 solid copper
- Above 10mm²: Class 2 stranded copper
- Insulation: Cross-Linked Polyethylene (XLPE)
- Filler: LSZH (Low Smoke Zero Halogen)
- Sheath: LSZH (Low Smoke Zero Halogen)
Standards & Compliance
- BS EN / IEC 60332-3-24 (Cat C), VDE 0276, EN 60228
- Flame retardant to IEC 60332-1-2
- Smoke emissions: IEC 61034-2, BS EN 60754-2, EN 60754-2
- Acid gas emissions: BS EN 60754-1
Why Choose Cleveland Cable?
- UK’s largest distributor of NYY & N2XH cables
- High-quality cables manufactured to British and international standards
- Competitive pricing with fast UK and international delivery
- Expert technical support for all cable requirements
- In-house BSI testing lab to ensure strict quality control
Order NYY & N2XH Cables Online or Contact Us
As the UK’s leading supplier of cables and cable accessories, Cleveland Cable Company provides high-quality NYY & N2XH cables for telecoms, construction, and power distribution applications.
At Cleveland Cable Company, we source our cables from trusted manufacturers and ensure they meet industry-specific requirements. Every product undergoes rigorous BSI-accredited lab testing, guaranteeing compliance and performance. This quality control process provides our customers with reliable and high-quality products.
