High-Quality Traffic Loop & Detector Cables for Traffic Management Systems
Cleveland Cable supplies Traffic Signal and Loop Feeder Cables designed for permanent traffic light systems, traffic detection loops, and urban traffic control infrastructure. Our cables comply with BS6346/87 and are available in armoured and unarmoured options for direct burial or duct installation. Our traffic detector loop cables are commonly used at traffic signals, pedestrian crossings, and motorway systems. They ensure reliable vehicle detection and enable accurate control of traffic lights and flow management.
Traffic Signal Cables for Permanent Installations
- BS6346/87 Non-Armoured Traffic Signal Cable – 1mm²
- BS6346/87 Armoured Traffic Signal Cable – 1mm² to 1.5mm²
- BS6346/87 Non-Armoured Loop Feeder Cable – 1.5mm² to 2.5mm²
- BS6346/87 Armoured Loop Feeder Cable – 1.5mm² to 2.5mm²
- BS6500, BS6195 Loop Detector Cable – 1.5mm² to 2.5mm²
All cables are engineered for durability, with options for harsh environments and mechanical stress resistance.
BS6346/87 Traffic Signal Cable (Unarmoured)
Key Features & Specifications
- Conductor: Plain Annealed Solid Copper
- Insulation: PVC
- Bedding: PVC
- Sheath: PVC
- Sheath Colour: Orange
- Voltage: 600/1000V
- Temp Range: -15°C to +70°C
- Application: Traffic signal cable to be used where mechanical protection isn’t required
BS6346/87 Traffic Signal Cable (armoured)
- Conductor: Plain Annealed Solid Copper
- Insulation: PVC
- Bedding: PVC
- Armour: GSWA
- Sheath: PVC
- Sheath Colour: Orange
- Voltage: 600/1000
- Temperature Range: -15°C to +70°C
- Application: Traffic signal cable to be used where mechanical protection is needed
Loop Feeder Cable (Unarmoured)
- Conductor: Plain Annealed Solid Copper
- Insulation: Polyethelene
- Bedding: PVC
- Sheath: Polyethelene
- Sheath Colour: Orange
- Voltage: 600/1000
- Temp Range: -15°C to +70°C
Loop Feeder Cable (Armoured)
- Conductor: Plain Annealed Solid Copper
- Insulation: Polyethelene
- Bedding: Polyethelene
- Armour: GSWA
- Sheath: Polyethelene
- Sheath Colour: Orange
- Voltage: 600/1000
- Temp Range: -15°C to +70°C
Loop Detector Cable
- Conductor: Tinned flexible copper
- Insulation: EPR
- Sheath: PCP (Black)
- Temp Range: -30°C to +85°C
- Standard: BS6195, BS6500, TR2029
- Suitable for harsh environments and traffic monitoring systems
Why Choose Cleveland Cable?
- Immediate stock availability for next-day UK delivery
- Full compliance with BS6346/87 and BS6500 standards
- Competitive pricing with bulk order discounts
- In-house BSI-certified testing lab
- Expert advice tailored to infrastructure and civil engineering projects
